| Business Type | Manufacturer, Supplier |
| Recovery Rate | 50–65% |
| Usage | Industrial |
| Automation Grade | Semi-Automatic |
| Click to view more | |
Product Details
We are Manufacturer, Supplier, Exporter of Demineralization ( DM ) Water Treatment Plants and Our setup is situated in Pune, Maharashtra, India.
We provide our entire range across ALL OVER INDIA and all African countries
Demineralization (DM) is the process of removing minerals, salts ( such as cations - sodium, calcium, iron, copper, and anions such as chloride, sulphate, nitrate, etc) from Water by using one of the following processes :
- Ion Exchange ( Cation- Anion- Mixed Bed) Treatment
- Membrane Filtration (Like Reverse Osmosis followed by MB )
- Electro DeIonisation (EDI)- RO+ EDI
- Distillation / Evaporation
Ion Exchange: Demineralised (DM) Water known for typical conductivity < 30 umhos/cm. Deionised (DI) Water is known as more purified DM water with the help of a Mixed Bed (MB )unit or Electro De-Ionisation (EDI). MB-based DI water produces Conductivity < 5 umhos/cm. EDI-based DI water produces Conductivity < 0.5 umhos/cm.
Envicare's DM Water Plant's Advantages:
- Variety of cost effective standard Manual & Auto models.
- Improved aesthetics and rugged design.
- User friendly, low maintenance and easy to install.
- Simpler distribution and collection systems.
- Quick availability.
- Pre dispatch assembly check.
- The multiport valves are top mounted as well as side mounted with the necessary high pressure rating PVC piping.
- Single valve operation as compared to the six valves in conventional filters
- Each operating step is clearly marked on the valve, thereby eliminating chances of error in the operating sequence.
- Single valve assembly, with its simplified frontal Piping, simpler distribution collecting systems is Very easy to install.
- Rust free
- Less power consumption
- Durable
- Economical
- High shelf life
Portable or Mini- DM Water Treatment Plant
The Water free from any mineral is called De-Mineralised Water (D.M.Water). Naturally occurring Water has various salts in dilute form which are called dissolved solids (TDS). When the Water having such mineral is required to be free from this, it is to be treated in Ion Exchange Resins column (H form) which adsorbs the positively charge ion. Now the cations free passed through Anion Resin Column (OH form) which adsorbs the negatively charged anions and Water free from the total ions shall comes out from the system.
Technical Specifications and Details
| 1 | Type | Mini DM Plant - Cabinet and Open Skid Type |
| 2 | Technology | Resin Based DM Plant |
| 3 | Model | eDM - 05 |
| 4 | Flowrate | Between 50 & 80 LPH |
| 5 | OBR (Output Between One Regeneration) | ~ 400 Lit @ 100 ppm Input water TDS ( best suitable for corporation feed water) |
| 6 | Output TDS | < 10 ppm |
| 7 | For better water quality < 1 ppm Output TDS | MB (Non Regenerative) - 05 Can be added |
| 8 | Size | Compact - Approx. 1.0 x 1.0 x 1.0 M |
